The last selected speed set option is displayed, in this case, Sequential. For each press of the
OPTIONS/TAB key, the display shows selectable options (Figure III-9). You must press the ENTER/
AUTORANGE key to select the ashing option.
É
DCGS UNITS è
DSEQUENTIAL ê
1
DCGS UNITS è
DINTERLEAVE ê
DCGS UNITS è
DCUSTOMSPEEDS ê
1
Figure III-9
The speeds available in each of the above options are listed in Appendix G. The DV-II+Pro is
initially set up with the Sequential Speed Set at Brookeld prior to shipment.
III.2.3.1 LV/RV Speeds
In the case of Sequential or Interleave, a press of the ENTER/AUTORANGE key immediately selects
that option and exits the SETUP option menu.
III.2.3.2 Custom Speeds
Pressing the ENTER/AUTORANGE key when Custom Speeds is displayed results in the following
screen display:
.01 h
°0.0 i
Figure III-10
Fifty-four (54) speeds are available for custom speed set selection (see Appendix G). You are
allowed to select up to nineteen (19) of these (54) available speeds. Speed 0.0 is automatically
included as one of the nineteen (19) speeds. Selecting a speed (or deleting a speed) is
accomplished by pressing the SET SPEED key while the desired speed is blinking. This will
cause an asterisk to appear (or to disappear if the speed is being cleared) to the left of the
speed. Trying to select more than nineteen (19) speeds will result in a “beep” for each press
of the SET SPEED key when over this limit. You may scroll up or down through the speed set in
selecting speeds. When done, a press of the ENTER/AUTORANGE key will take you back to the
default screen with the asterisked speeds now comprising the custom speed set. Regardless of
order chosen, speeds will appear in ascending order for run selection, beginning with speed 0.0
RPM.
