Brookeld Engineering Labs., Inc. Page 41 Manual No. M/03-165-D0410
Figure IV-1
IV.3 Creating a B.E.V.I.S. Program
Start the DVLOADER software by clicking on its associated icon. For Windows 95/98/
NT/2000, click the Start button; select Run; enter the name of the program to execute
{dvloader.exe}; then click OK.
The B.E.V.I.S. commands are displayed in a list box on the main screen. This list box displays
the commands available for creating programs. Clicking on the Insert button inserts the
highlighted command (WTI, as shown in Figure IV-1) into the selected line in the program
grid. Double-clicking on a line in this list box also inserts the command into the grid shown in
Figure IV-2.
The icons to the left of the command descriptions indicate
the type of command:
A command to wait for a condition.
A command to set a program parameter.
A command to send information to an attached
printer.
