Brother BAS-342G Service Manual

2. FUNCTION SETTINGS
7
BAS-342G
No.
Setting
value
Setting item
Default
value
Work clamp operation before home position detection
OFF Work clamp cannot be raised or lowered before home position detection (*5)
051
ON Work clamp can be raised and lowered before home position is detected
ON
Work clamp operation during split programs
OFF Work clamp is raised automatically when sewing pauses due to a split program
052
ON
Work clamp is raised if the work clamp switch is depressed when sewing pauses
due to a split program
OFF
Time from intermittent presser foot lifting until feed mechanism starts moving
053
0 - 999 [Units ms]
100
Intermittent presser foot lowering timing
0
Intermittent presser foot is lowered when the work clamp switch is depressed, but
it is not lowered at the feed retract position.
1 Intermittent presser foot is lowered when the work clamp switch is depressed.
054
2
Intermittent presser foot is lowered at the sewing start, regardless of the work
clamp switch operation.
0
Work clamp signal valve special output for pneumatic-type work clamp
0 Disabled
1
Valve output is reversed for pneumatic specifications
(Switch the air tube connections so that the work clamp can lift when the power is
turned off.)
055
2
Reverse valve output is output simultaneously for 2-position valve specifications.
(Right work clamp reverse = Option output No. 4, Left work clamp reverse =
Option output No. 5: When using a separate-type work clamp)
0
Thread winding operation before home position is detected
OFF Thread winding cannot be carried out before home position is detected.
056
ON Thread winding can be carried out before home position is detected. (*5)
OFF
Work clamp operation when feed moves to sewing start position after home position is detected
OFF
Work clamp stays lowered after home position is detected
Work clamp rises when the work clamp switch is depressed.
057
ON
Work clamp lifts automatically after home position is detected.
* Disabled when memory switch No. 050 = 2 or 4.
ON
Work clamp operation at sewing end
OFF
Work clamp lifts automatically at the sewing end.
* Disabled when memory switch No. 050 = 2 or 4.
058
ON Work clamp does not lift automatically at the sewing end
OFF
Weight of work clamp
-1 Light (no work clamp)
0 Standard
059
1 Heavy
0
*5 If the thread winding operation is to be carried out before home position detection, first carry out operations such as
lowering the intermittent presser foot to check that the needle does not interfere with any other parts when it is being
raised and lowered. In addition, if raising and lowering of the work clamp is disabled before home position detection is
carried out, thread winding cannot be carried out before home position detection, regardless of the setting for memory
switch No. 056.
