2. FUNCTION SETTINGS
22
BAS-342G
2-9. Software version checking method
TEST indicator illuminates, Menu indicator switches off
1. While pressing the key (1), turn on the power. The software version will be displayed in the menu display (2).
* Keep pressing the
key (1) until the model name is displayed and the buzzer beeps once.
2. The display in the PROGRAM No. display (4) switches as follows each time the or key (3) is pressed.
PROGRAM No. display (4) Software
[1.Mn] Main CPU
[2.Mt] Motor CPU
[3.PL] Panel CPU
[4.iP] Main CPU (IPL)
[5.PG] Programmer
3. When the TEST key (5) is pressed, the display will return to the normal display and the sewing machine will change to
home position standby.
5059Q
