Brother BAS-342G Service Manual

3. READING / WRITING DATA
34
BAS-342G
3-16. Writing extended option output data to CF cards
1
Select the [w 12] data read/write mode.
2
Writing
Press the R/W key.
• The buzzer will sound and the extended option output
data will be copied from the internal memory onto the
CF card.
3
End data read/write mode
TEST indicator switches off
Press the TEST key.
Turn off the power switch, remove the CF card, and then
close the cover of the CF slot.
3-17. Reading extended option output data from floppy disks
1
Insert the floppy disk into the floppy disk drive.
2
Select the [r 13] data read/write mode.
3
Loading
Press the R/W key.
• The buzzer will sound and the extended option output
data will be loaded from the floppy disk and copied into
the sewing machine's internal memory.
4
When [ End] is displayed, the process is complete.
Turn off the power and remove the floppy disk.
5070Q
5069Q
5068Q
4579Q
5067Q
