3. READING / WRITING DATA
26
BAS-342G
3-5. Reading sewing data from CF cards
1
Select the [r 1] data read/write mode.
2
Press the R/W key.
• [-SEd] will change to [ ALL].
Press the
or key to select the program number (100 - 999) to be
read.
* If [ ALL] is selected, all sewing data (Nos. 100 - 999) will be read at
once.
[When memory switch No. 755 is ON]
The program number (0 − 99) is also displayed and can be selected.
If you select [ ALL] at this time, all sewing data (Nos. 0 - 999) will be
read at once.
3
Loading
Press the R/W key.
• The buzzer will sound and the selected sewing data will be loaded
from the CF card and copied into the sewing machine's internal
memory.
• The program numbers that have been read will be displayed in the
menu display.
* If there is a large volume of data in the CF card, it will take some time
for all of it to be read. To halt the reading of data, press the STOP
switch. If you then press the RESET key, the display will change back
to [ ALL].
4
End data read/write mode
TEST indicator switches off
Press the TEST key.
Turn off the power switch, remove the CF card, and then close the cover
of the CF slot.
4976Q
4576Q
4577Q
To Next Page
