Brother BAS-342G Service Manual

3. READING / WRITING DATA
28
BAS-342G
3-7. Reading memory switch data from CF cards
1
Select the [r 3] data read/write mode.
2
Loading
Press the R/W key.
• The buzzer will sound and the memory switch data will
be loaded from the CF card and copied into the sewing
machine's internal memory.
3
When [ End] is displayed, the process is complete.
Turn off the power switch, remove the CF card, and then
close the cover of the CF slot.
3-8. Writing memory switch data to CF cards
1
Select the [w 4] data read/write mode.
2
Writing
Press the R/W key.
• The buzzer will sound and the memory switch data will
be copied from the internal memory onto the CF card.
3
End data read/write mode
TEST indicator switches off
Press the TEST key.
Turn off the power switch, remove the CF card, and then
close the cover of the CF slot.
4581Q
4498Q
4580Q
4582Q
4579Q
