Brother BAS-342G Service Manual

2. FUNCTION SETTINGS
18
BAS-342G
PROGRAM No. display Menu display
Check code Name Input status
Check item and checking method
[ 8] [ UP] [ on]/[oFF]
Needle up signal
Turn the pulley by hand.
[ 9] [ dn] [ on]/[oFF]
Needle down signal
Turn the pulley by hand
[ 10] [voL] [0] - [300]
Power supply voltage
Displayed as %
[ 11] [PnL] [*]/[ oFF]
Operation panel key input check
While a key is being pressed, the name of the key will be
displayed.
* ON display Key name
[rESt] RESET key
[tESt] TEST key
[tHrE] THREAD/CLAMP key
[ tEn] TENSION/WIND key
[SELE]
SELECT key
[UP-M] key
[dn-M] key
[ F1] Function key F1
[ F2] Function key F2
[ F3] Function key F3
[ F4] Function key F4
[ CF] R/W key
[ 12] [FtA] [0] - [255]
Foot switch analog value (when one pedal is installed)
Depress the foot switch.
[ 13] [CL1] [ on]/[oFF]
Work clamp switch 1st step
Depress the work clamp switch to the 1st step.
[ 14] [CL2] [ on]/[oFF]
Work clamp switch 2nd step
Depress the work clamp switch to the 2nd step.
[ 15] [Stt] [ on]/[oFF]
Start switch
[ 16] [EMC]
[--on]
[on--]
[----]
STOP switch
Press the STOP switch.
[ 17] [HEd] [ on]/[oFF]
Safety switch
Tilt back the machine head.
[ 18] [Air] [ on]/[oFF] External input error detection (IN13)
[ 19] [FnX] [ on]/[oFF] Cooling fan for X pulse motor
[ 20] [FnY] [ on]/[oFF] Cooling fan for Y pulse motor
[ 21] [in1] [ on]/[oFF] Option input (IN1)
[ 22] [in2] [ on]/[oFF] Option input (IN2)
[ 23] [in3] [ on]/[oFF] Option input (IN3)
[ 24] [in4] [ on]/[oFF] Option input (IN4)
[ 25] [in5] [ on]/[oFF] Option input (IN5)
[ 26] [rot] [ on]/[oFF] No devices are compatible with the BAS-342G.
[ 27] [Fib] [ on]/[oFF] Fiber-type thread breakage detection (option) (IN14)
