Brother DCP-L5600DN Service Manual

5-55
Confidential
RE_JAM:00000000 Paper jams that have occurred at the ejecting section or back
cover
DX_JAM:00000000 Paper jams that have occurred in the duplex tray
POWER:00000375 Total power distribution time (unit: hour)
PWRCNT:00000001 The number of times that the power is turned ON
KTN_CH:0000
The number of times that the toner cartridge has been replaced
*4
DRUM_CH:0000
The number of times that the drum unit has been replaced
*4
FUSR_CH:0000
The number of times that the fuser unit has been replaced
*4
LASR_CH:0000
The number of times that the laser unit has been replaced
*4
PFMP_CH:000 The number of times that the PF kit MP has been replaced
PFK1_CH:000 The number of times that the PF kit 1 has been replaced
PFK2_CH:000 The number of times that the PF kit 2 has been replaced
PFK3_CH:000 The number of times that the PF kit 3 has been replaced
PFK4_CH:000 The number of times that the PF kit 4 has been replaced
PFK5_CH:000 The number of times that the PF kit 5 has been replaced
KTN_PG1:00000000 Pages printed with the current toner cartridge
KTN_PG2:00000000 Pages printed with the previous toner cartridge
WTNR_PG:00000000
The number of pages printed from the waste toner box
SCN_PG:00000000
The number of scanned pages (except Fax and Copy)
ADSX_PG:00000000
ADF single-side scanned pages (duplex scanning models only)
ADDX_PG:00000000
ADF double-side scanned pages (duplex scanning models only)
ADTL_PG:00000000
Total pages of ADSX_PG and ADDX_PG
FB_PG:000000
Total FB scanned pages
ADSX_JAM:000000
Document jams that have occurred on ADF single-side scanning
(duplex scanning models only)
ADDX_JAM:000000
Document jams that have occurred on ADF duplex scanning
(duplex scanning models only)
FXTX_PG The number of faxed pages
COMERR#:00000000
Communication error log (past three errors)
*5
(models with fax only)
KDEV_BIAS:400V Black developing bias voltage value
ENGERR##:000000
Engine error log (last ten errors)
*6
HODN_ER:0000 The number of discharge errors occurred
FUSR_ER:0000 The number of fuser unit errors occurred
MTLK_ER:0000
The number of polygon motor lock errors occurred in the laser scanner
DEVSTATUS__##:00
Log for design analysis
*7
LCD Description
