Brother DCP-L5600DN Service Manual

2-17
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
7602
When printing from the paper tray 4,
the registration front sensor or the T2/
T3/T4TT jam sensor does not detect
paper pass within the specified time
after the T4(LT or TT) paper feed
sensor detected paper pass.
2-59
7C00 ―
7701
When printing from the paper tray 5,
the T5TT paper feed sensor does not
detect paper pass within the specified
time while the T5TT paper empty
sensor detects some paper set.
2-60 7D00 ―
7702
When printing from the paper tray 5,
the registration front sensor or the T2/
T3/T4/T5TT jam sensor does not
detect paper pass within the specified
time after the T5TT paper feed sensor
detected paper pass.
2-61
7E00 ―
7800
The registration front sensor does not
detect paper pass within the specified
time after the first side was printed in
duplex printing mode.
2-62
7F00 ―
7801 ― 8000 ―
7802 ― 8100 ―
7803 ― 8401 ―
7804 ― 8402 ―
7805 ― 8403 ―
7900 ― 8501
When printing from paper tray 1 to 5,
the T1 paper feed sensor detected
open paper tray 1 (before registering
printing data to engine).
2-63
7A01 ― 8502
When printing from paper tray 2 to 5,
the T2(LT or TT) paper feed sensor
detected open paper tray 2 (before
registering printing data to engine).
2-63
7A02 ― 8503
When printing from paper tray 3 to 5,
the T3(LT or TT) paper feed sensor
detected open paper tray 3 (before
registering printing data to engine).
2-63
7B01 ― 8504
When printing from paper tray 4 to 5,
the T4(LT or TT) paper feed sensor
detected open paper tray 4 (before
registering printing data to engine).
2-63
7B02 ― 8505
When printing from paper tray 1 to 5,
the T1 paper feed sensor detected
open paper tray 1 (after registering
printing data to engine).
2-64
7B03 ― 8506
When printing from paper tray 2 to 5,
the T2(LT or TT) paper feed sensor
detected open paper tray 2 (after
registering printing data to engine).
2-64
7B04 ― 8507
When printing from paper tray 3 to 5,
the T3(LT or TT) paper feed sensor
detected open paper tray 3 (after
registering printing data to engine).
2-64
7B05 ― 8508
When printing from paper tray 4 to 5,
the T4(LT or TT) paper feed sensor
detected open paper tray 4 (after
registering printing data to engine).
2-64

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
