Brother DCP-L5600DN Service Manual

2-18
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
8601 ― 8903
The back cover/duplex tray sensor
detected that the cover was open
when duplex printing is started.
(Before registering printing data to
engine)
2-65
8602 ― 8904
The back cover/duplex tray sensor
detected that the cover was open
during duplex printing. (After
registering printing data to engine)
2-65
8603 ― 8A01
The registration rear sensor detected
that the paper fed was smaller or
larger than the specified size in duplex
printing mode.
2-65
8604 ― 8A02 ―
8701 ― 8B01
Detected that the TT was not turned
ON.
2-66
8702
Machine stack sensor detected the
ejected paper full state at the start of
printing.
2-64
8C00 ―
8703 ― 8D01 ―
8708 ― 8D02 ―
8709 ― 8E01 ―
870A ― 8E02
Detected that the size of paper set in
the paper tray was over 10 mm shorter
than letter size during receiving fax
data or printing a list or report.
2-66
870B ― 8F01 ―
870C ― 8F02 ―
870D ― 8F03 ―
870E ― 9001
When printing from the MP tray, the
size of paper set in the MP tray does
not match the size specified by the
driver.
2-67
870F ― 9002
When printing from the paper tray 1,
the size of paper set in the paper tray
1 does not match the size specified by
the driver.
2-67
8801 ― 9003
When printing from the paper tray 2,
the size of paper set in the paper tray
2 does not match the size specified by
the driver.
2-67
8802 ― 9004
When printing from the paper tray 3,
the size of paper set in the paper tray
3 does not match the size specified by
the driver.
2-67
8808 ― 9005
When printing from the paper tray 4,
the size of paper set in the paper tray
4 does not match the size specified by
the driver.
2-67
8809 ― 9006
When printing from the paper tray 5,
the size of paper set in the paper tray
5 does not match the size specified by
the driver.
2-67
880A ― 9102 ―
8901 ― 9103 ―
8902 ― 9104 ―

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
