Brother DCP-L5600DN Service Manual

2-19
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
9105 ― 9502 ―
9200 ― 9503 ―
9201
When printing from the MP tray, paper
type setting in the machine does not
match the setting in the driver.
2-68 9504 ―
9202
When printing from the paper tray 1,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9505 ―
9203
When printing from the paper tray 2,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9601 ―
9204
When printing from the paper tray 3,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9608 ―
9205
When printing from the paper tray 4,
paper type setting in the machine
does not match the setting in the
driver.
2-68 9701
A tray set to duplex printing-
incompatible size was specified in
duplex printing.
2-72
9206
When printing from the paper tray 5,
paper type setting in the machine
does not match the setting in the
driver.
2-68 9702
When printing from paper tray 1, a
paper size not supported for paper
tray 1 was specified from the driver.
2-72
9301
When printing from the MP tray, the
MP paper empty sensor detected that
there was no paper set in the MP tray.
2-69 9703
When printing from paper tray 2, a
paper size not supported for paper
tray 2 was specified from the driver.
2-72
9302
When printing from paper tray 1, the
T1 paper empty sensor or the T1
paper feed sensor detected that there
was no paper set in paper tray 1.
2-69 9704
When printing from paper tray 3, a
paper size not supported for paper
tray 3 was specified from the driver.
2-72
9303
When printing from paper tray 2, the
T2(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 2.
2-69 9705
When printing from paper tray 4, a
paper size not supported for paper
tray 4 was specified from the driver.
2-72
9304
When printing from paper tray 3, the
T3(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 3.
2-69 9706
When printing from paper tray 5, a
paper size not supported for paper
tray 5 was specified from the driver.
2-72
9305
When printing from paper tray 4, the
T4(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 4.
2-69
9801 ―
9306
When printing from paper tray 5, the
T5TT paper empty sensor detected
that there was no paper set in paper
tray 5.
2-69
9802 ―
9309
Detected that there was no paper set
in all trays when TrayAuto was
selected for printing.
2-70 9803 ―
930A
Paper ran out during Fax / List
continuous printing.
2-71
9804 ―
9400
Firmware version of the main PCB is
older than that of the TT and LT.
2-71
9901 ―
9501 ― 9902 ―

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
