Brother GTX-4 - 6-2. Tasks to Be Performed Before Starting Print Operation; 6-2-1. Confirmation and Disposal of Waste Ink

4-28
Improvement of print quality
Cleaning wiper
(1) Use clean stick R to wipe clean the surface of the wiper as well as the gap between the convex part and the wiper.
<IMPORTANT>
 Never touch the tip end of clean stick R with your hand. If any sebaceous matter is attached to the wiper, it may result in a
printer malfunction.
 The clean stick R used for cleaning the nozzle guard should be rinsed in the cleaning cup before the next use. Be sure to
use the clean stick R separately for color ink and white ink.
(2) Use the clean side of clean stick R to wipe clean the back of the wiper.
X0195
(3) Rinse the clean stick R in the cleaning cup to use it for cleaning of the exhaust cap to be performed next.
<IMPORTANT>
 Be sure to use the clean stick R separately for white ink and color ink.
Wiper
Clean stick R
Front
Back
Front
Wiper
Clean stick R
Convex part
