1-31
Before Using Your Printer for the First Time
Correct Way of Operation
・If the ink pouch contains large quantities of ink, the lock is not unlocked and wind-up does not occur.
・When the remaining ink level becomes low, the lock is unlocked and ink pouch wind-up starts (before the remaining ink
volume drops below approx. 400 g).
・The ink level detection plate moves according to the wind-up shaft position and the remaining ink level is displayed on
the display panel.
X022
Sliding tape
The lock is unlocked
Ink level
detection
plate
Upper portion
To Next Page
