MAINTENANCE MANUAL LINE
Option 3
Step
Procedure
1
Remove hex. screw M6x6 from intake manifold and connect the vacuum
gauge.
2
Remove the compensation hose with attached resonator hose(connection
between intake manifolds) and plug the fittings in the intake manifolds.
3
After synchronization, tightened the screw M6x6 with LOCTITE 243.
2
1
4
3
1
2
4
AE_912_0088
Figure 7.19: Option 3
1 Hex. screw M6x6 2 Intake manifold
3
Compensation tube
4 Resonator hose
Option 4
Step
Procedure
1
Remove hex. screw M6x6 from intake manifold and connect the vacuum
gauge.
2 Remove the compensation hose with attached resonator hose(connection
between intake manifolds) and plug the fittings in the intake manifolds.
3
After synchronization tightened the screw M6x6 with LOCTITE 243.
12–20–00
Page 30
January 01 2020
Effectivity: 912 Series
Rev. 0
