PULSE Multi-analyzer System Type 3560-B/C/D/E – Installation and IDAe Hardware114
EFFECT OF RADIATED/CONDUCTED RF,
MAGNETIC FIELD AND VIBRATION
Radiated RF: 80 − 1000 MHz, 80% AM 1 kHz, 10 V/m
Conducted RF: 0.15 − 80 MHz, 80% AM 1 kHz, 10 V
Magnetic Field: 30 A/m, 50 Hz
Vibration: 5− 500 Hz, 12.7 mm, 15 m/s
2
Input measured in 7.071 mV range with shorted input.
All values are RMS. Conducted RF immunity on all
channels is only guaranteed using an external
connection from measuring ground to chassis terminal
on Types 2826 or 2827
Specifications – PULSE Types 3560-B/C/D/E
Multi-analyzer Systems Type 3560-B, 3560-C, 3560-D
and 3560-E with LAN interface are modular,
expandable, multi-analysis systems that include the
following components:
•Pentium
®
PC (UL-0176-A-xx
a
recommended)
• PULSE software
•Microsoft
®
Windows
®
2000 or Windows
®
XP or Win-
dows Vista
®
operating system
•Microsoft
®
Office 2000, 2003, 2007 or XP
• Front-end comprising: Power Supply/Frame, Con-
troller Module and a number of Input/Output Mod-
ules (see below)
Specifications – Portable PULSE Type 3560-B
POWER REQUIREMENTS
Fulfils the requirements of ISO 7637–1 and 7637–2
with batteries
Voltage: 10 – 32 V DC
Power Consumption:
Nominal: 14 W
Max.: 26 W (while charging battery)
Ext. Power Connector: LEMO coax., FFA.00.113,
ground on shield
BATTERIES
Optional Accessories: 2 × DR35 NiMH or NI 1030,
10.8 V (nominal)
Working Time (Continuous): 5hours
Charging Time: 5 hours/battery
ACOUSTIC NOISE EMISSION (at 1 m)
Silent operation to 35°C (95°F) when not charging
batteries. When charging batteries, fan operation may
start at a lower ambient temperature
DC OUTPUT
+5V ± 0.5 V; max. 0.4 A (1 A fused)
+12 V ± 1.0 V; max. 0.4 A (1 A fused)
Connector: LEMO FGG.00.302
DIMENSIONS (WITHOUT PROTECTIVE COVER)
Height: 182 mm (7.2″)
Width: 64 mm (2.5″)
Depth: 270 mm (10.6″)
Weight: 2.5 kg (5.5 lb.) without batteries
Mechanical Operating (peak values)
MIL−STD − 810C: Vibration: 12.7 mm, 15 ms
−2
, 5 − 500 Hz
Non-operating:
IEC 60068−2−6: Vibration: 0.3 mm, 20 ms
−2
, 10 −500 Hz
IEC 60068−2−27: Shock: 1000 ms
−2
IEC 60068−2−29: Bump: 1000 bumps at: 250 ms
−2
Enclosure IEC 60529: Protection provided by enclosures: 3560-B: IP 40; 3560-C: IP 32; 3560-D: IP 40;
3560-E: IP 20
Input/Output Radiated RF Conducted RF Magnetic Field Vibration
Direct/CCLD <10 μV<130μV<4μV<80μV
Preamplifier <10 μV<25μV<8μV<80μV
Generator <60 μV<25μV<4μV<5μV
Charge <130 fC <130 fC <10 fC <80 fC
a.xx specifies country: GB, DE, FR, ES, IT, SE, DK, US
