CHAPTER 11
Specifications
115
Specifications – Portable PULSE Type 3560-C
POWER SUPPLY/FRAME
Type 2827
POWER REQUIREMENTS
Fulfils the requirements of ISO 7637−1 and 7637−2
with batteries
Voltage: 10 − 32 V DC
Power Consumption:
Without DC output and when fitted with:
1 × 7536 Controller Module
1 × 3109 4/2-ch. or 3110 2/1-ch. Input/Output Module
Nominal: 30 W
Max.: 42 W (while charging battery)
Ext. Power Connector: LEMO coax., FFA.00.113,
ground on shield
BATTERIES
Optional Accessories: 2 × DR35 NiMH or NI 1030,
10.8 V (nominal)
Working Time (Continuous): 2½ hours
Charging Time: 5 hours/battery
ACOUSTIC NOISE EMISSION (at 1 m)
DC OUTPUT
+5 V ± 0.5 V; max. 0.4 A (1 A fused)
+12 V ± 1.0 V; max. 0.4 A (1 A fused)
Connector: LEMO FGG.00.302
DIMENSIONS (WITHOUT PROTECTIVE COVER)
Height: 105 mm (4.1″)
Width: 376 mm (14.8″)
Depth: 300 mm (11.8″)
Weight: 5 kg (11 lb.) with Controller Module and Input/
Output Module. When fitted with batteries, 6 kg (13 lb.)
Specifications – Multichannel Portable PULSE Type 3560-D
POWER SUPPLY
Type 2826
FRAME (INCL. FAN UNIT)
KK-0050
POWER REQUIREMENTS
Voltage: 10 − 32 V DC
Power Consumption:
Without DC output and when fitted with:
1 × 7536 Controller Module
35 W nominal with 1 input module
100 W nominal with 5 input modules
Ext. Power Connector: Neutrik
®
Powercon 3-pole
Max. No. of Tacho Probes: 4 in full frame
DC OUTPUT
+5 V ± 0.5 V; max. 0.4 A (1 A fused)
+12 V ± 1.0 V; max. 0.4 A (1 A fused)
Connector: LEMO FGG.00.302
ACOUSTIC NOISE EMISSION (at 1 m)
DIMENSIONS
Height: 194 mm (7.6″) with feet, 170 mm (6.7″)
without feet
Width: 376 mm (14.8″)
Depth: 342 mm (13.5 ″)
Weight: 10 kg (22 lb.) with Controller Module and 5
Input/Output Modules
dB SPL,
A-weighted at 1 m
dB Lw,
A-weighted
Fan Off <17 <25
Normal
(22°C)
32 40
Max. 33 41
dB SPL,
A-weighted at 1 m
dB Lw,
A-weighted
Fan Off 27 35
Normal
(22°C)
30 38
Max. 42 50
