System Components
H157655_1_008 23
3.5 Other Optional Components
Figure3.4: Other Options for AVANCE Systems
1. SampleCase is a 24 sample, random-access, automation system that fits almost
all shielded Bruker standard bore magnets.
2. SampleJet is a robot which has been consciously designed to meet growing
demand for simplicity, versatility and higher throughput in NMR sample tube
automation.
3. SampleXpress allows automatic measurement of NMR samples with Bruker
NMR spectrometers. SampleXpress is controlled by TopSpin or IconNMR, and is
equipped with integrated barcode reader registration, which is under control of
SampleTrack.
4. The imaging accessory cabinet houses the gradient amplifiers for micro-
imaging applications.
5. An optional UPS (not shown) is highly recommended and may vary based on
the system configuration.
