Bruker AVANCE User Manual

Magnetic Stray Fields
H157655_1_008 41
6.2 Vertical Stray Fields
Magnet Type 5.0 mT
(50 G)
3.0 mT
(30 G)
1.0 mT
(10 G)
0.5 mT
(5 G)
0.2 mT
(2 G)
0.1 mT
(1 G)
0.05 mT
(0.5 G)
400/54 Ascend Aeon 0.64 0.70 0.87 1.00 1.24 1.47 1.77
500/54 Ascend Aeon 0.80 0.87 1.06 1.20 1.48 1.75 2.09
600/54 Ascend Aeon 0.90 0.99 1.21 1.40 1.71 2.03 2.45
700/54 Ascend Aeon 0.99 1.09 1.37 1.60 2.01 2.42 2.95
Distances are measured in axial direction from magnetic center.
Table6.4: Vertical Stray Fields: Standard Bore 54 mm
Magnet Type 5.0 mT
(50 G)
3.0 mT
(30 G)
1.0 mT
(10 G)
0.5 mT
(5 G)
0.2 mT
(2 G)
0.1 mT
(1 G)
0.05 mT
(0.5 G)
400/89 Ascend Aeon 0.79 0.86 1.05 1.20 1.45 1.70 2.02
500/89 Ascend Aeon 0.88 0.97 1.21 1.40 1.73 2.07 2.49
600/89 Ascend Aeon 1.02 1.12 1.38 1.60 1.97 2.34 2.81
700/89 Ascend Aeon 1.56 1.72 2.15 2.50 3.09 3.67 4.41
Distances are measured in axial direction from magnetic center.
Table6.5: Vertical Stray Fields: Wide Bore 89 mm
