Bruker AVANCE User Manual

Utility Requirements
58 H157655_1_008
System and
Amplifiers
Mains Supply Power
Consumpt
ion (kW)*
No. of
Spare
Electrical
Outlets
Length of
Mains
Cable (m)
TwoBay with
BLARH100 +
BLAX300
230V 50/60 Hz / 16A single
phase; or 208V 60 Hz / 20A
single phase in USA
2.6 4 (230V
max. 10
amp.)
5.5
TwoBay with
BLAXH300/50
230V 50/60 Hz / 16A single
phase; or 208V 60 Hz / 20A
single phase in USA
2.2 4 (230V
max. 10
amp.)
5.5
TwoBay optimized
for solids 300 to
700 MHz
230V 50/60 Hz / 32A single
phase or 400V 50/60 Hz /
16A triple phase; or 208V 60
Hz / 30A single phase in
USA
5.0 4 (230V
max. 10
amp.)
5.5
OneBay with
BLAXH100/50
230V 50/60 Hz / 16A single
phase; or 208V 60 Hz / 20A
single phase in USA
1.6
2.2
4 (230V
max. 10
amp.)
5.5
NanoBay 230V 50/60 Hz / 16A single
phase; or 208V 60 Hz / 20A
single phase in USA
1.0 --- 5.5
Imaging Cabinet 230V 50/60 Hz / 32A single
phase or 400V 50/60 Hz /
16A triple phase; or 208V 60
Hz / 30A single phase in
USA
2.4 --- ---
Bayvoltex Chiller
for MicroImaging
Systems
230V 50/60 Hz / 16A single
phase or 208V 60 Hz / 20A
single phase in USA
approx.
0.45 kW
--- ---
BCU-I/BCU-II 230V 50/60 Hz / 16A single
phase or 208V 60 Hz / 20A
single phase in USA (power
for BCU-II must come from
separate outlet).
0.45 kW
(BCU-I)
2.3 kW
(BCU-II)
--- ---
UPS for CCU UPS requirements: At least 5 kW for the AVANCE and CCU.
UPS for AVANCE
Spectrometer
Cabinet
UPS requirements: At least 2.6 kW for the spectrometer cabinet
(depends on configuration). The battery time must be selected
according to the maximum duration anticipated for a power failure.
* Includes the NMR workstation and computer monitor, and was measured using 2
amplifiers operating at maximum output in CW mode. For systems fitted with additional
amplifiers allow 300W for each additional amplifier.
Note: For the electrical specifications associated to the CryoProbe, CryoProbe - Prodigy,
and the Bruker Nitrogen Liquifier accessories, refer to the relevant pages in CryoProbe
and Other Accessories [}83].
Table8.1: Requirements of Basic System (2 Channels)
