9.2 Dimensions and Mass of Equipment
The floor of the NMR laboratory must be sufficiently strong to support the magnet, the
spectrometer, and other ancillary equipment. The following tables provide the dimensions
and weights of equipment, and the footprint and weight of magnets (filled with cryogens and
including stand). The assembly of the magnet system, the magnet energization and refills
with liquid helium require additional ceiling height.
Component Width (m) Depth (m) Height (m) Weight (kg)
AVANCE TwoBay 1.31 0.83 1.55 454
AVANCE OneBay 0.69 0.83 1.29 ~210
AVANCE NanoBay 0.45 0.88 0.71 130
Table / Workstation 1.20 1.00 0.75 68
MicroImaging Cabinet 0.69 0.83 1.55 205 / 150
BCU-I 0.50 0.55 0.48 46
BCU-II 0.55 0.59 0.74 74
Prodigy Unit 0.60 0.40 0.46 68
For the CryoProbe option refer to CryoProbe and Other Accessories [}83].
Table9.1: Dimensions and Weights of NMR Equipment
9.3 Floor Load
The floor must be sufficiently strong to support the mass of the equipment, plus the weight of
any installation devices, e.g. hoists etc. The floor must also be as rigid as possible to reduce
the effects of vibration.
The overall floor load may be calculated from the total magnet weight distributed over the
overall footprint of the magnet.
The magnet is supported by a total of 9 small pads (3 pads per post). The maximum point
load may be calculated by the total weight of the magnet distributed over the total contact
area of the 9 points. Each pad is circular and has a diameter of 80 mm.
