Bruker AVANCE - Layout Examples; Figure 9.4: Ascend 400 Layout Example

Floor Plan
80 H157655_1_008
9.12 Layout Examples
The following layout examples of some NMR systems include the equipment and utilities. A
description of each of the NMR system components is presented in the chapter System
Components [}19], while the details regarding the utility requirements are presented in the
chapter Utility Requirements [}57].
If a CryoProbe System is planned, be sure to refer to CryoProbe and Other Accessories
[}83] for specific information on CryoProbe site requirements.
Figure9.4: Ascend 400 Layout Example
