Bruker AVANCE User Manual

Magnet Access and Rigging
28 H157655_1_008
Accessories Crate Size - including stand if
applicable (m)
Magnet Stand L D H
400/89 Ascend Aeon F95 950 API 1.32 0.74 1.29
500/89 Ascend Aeon F95 950 API 1.32 0.74 1.29
600/89 Ascend Aeon F95 950 API 1.32 0.74 1.29
700/89 Ascend Aeon F110 950 API 1.32 0.74 1.29
Pallet is integrated in crate. Add 2-10 cm for pallet jack depending on floor quality. Allow
at least 1 cm clearance on the sides and above the crate.
Table4.4: Door Dimensions for Magnet Stand: Wide Bore 89 mm
4.3.3 Magnet Transport Weights
Magnet Type Magnet Weight with
Crate (kg)
Magnet Weight w/o
Crate & Stand (kg)
400/54 Ascend Aeon ~600 ~490
500/54 Ascend Aeon ~700 ~590
600/54 Ascend Aeon ~1000 ~850
700/54 Ascend Aeon ~1300 ~1150
The weights of the accessories are approximations. The actual weight may vary
depending on the options and accessories that are ordered.
Table4.5: Magnet Transport Weights: Standard Bore 54 mm
Magnet Type Magnet Weight with
Crate (kg)
Magnet Weight w/o
Crate & Stand (kg)
400/89 Ascend Aeon ~970 ~785
500/89 Ascend Aeon ~1050 ~865
600/89 Ascend Aeon ~1300 ~1120
700/89 Ascend Aeon ~1900 ~1740
The weights of the accessories are approximations. The actual weight may vary
depending on the options and accessories that are ordered.
Table4.6: Magnet Transport Weights: Wide Bore 89 mm
