Bruker AVANCE User Manual

Magnet Access and Rigging
H157655_1_008 27
Crate Size (m) Magnet Transport Dimensions (m)
(for transport to the magnet room)
System
(MHz/mm)
L D H Width
Uncrated
Height
Uncrated w/
o Pallet
Jack*
Height
Uncrated
with Pallet
Jack**
400/89 Ascend Aeon 1.15 1.35 2.08 0.85 1.53 1.64
500/89 Ascend Aeon 1.15 1.36 2.02 0.95 1.74 1.85
600/89 Ascend Aeon 1.15 1.35 2.08 0.85 1.53 1.64
700/89 Ascend Aeon 1.50 1.30 2.14 0.85 1.53 1.64
* Measured from magnet bottom plate to helium tower - this is the absolute minimum
height!
** The heights listed with pallet jack assume that the floor is level, thus the magnet needs
only to be jacked up approx. 2 cm for transport. If the floor is uneven, the magnet may
need to be jacked up accordingly, which could add as much as 9 cm to the transport
height.
Table4.2: Door Dimensions: Wide Bore 89 mm
4.3.2 Magnet Stand Transport Dimensions
Door Dimensions for Magnet Stand & Accessories Access
Accessories Crate Size - including stand if
applicable (m)
Magnet Stand L D H
400/54 Ascend Aeon F85 570 ADI 0.97 0.76 1.20
400/54 Ascend Aeon F85 700 ADI 0.97 0.76 1.20
400/54 Ascend Aeon F85 570 API 0.97 0.76 1.20
400/54 Ascend Aeon F85 700 API 0.97 0.76 1.20
500/54 Ascend Aeon F85 570 ADI 0.97 0.76 1.20
500/54 Ascend Aeon F85 700 ADI 0.97 0.76 1.20
500/54 Ascend Aeon F85 570 API 0.97 0.76 1.20
500/54 Ascend Aeon F85 700 API 0.97 0.76 1.20
600/54 Ascend Aeon F95 700 API 1.77 0.97 1.11
700/54 Ascend Aeon F95 700 API 1.77 0.97 1.11
Pallet is integrated in crate. Add 2-10 cm for pallet jack depending on floor quality. Allow
at least 1 cm clearance on the sides and above the crate.
Table4.3: Door Dimensions for Magnet Stand: Standard Bore 54 mm
