10.2.2.2 Outdoor Helium Compressors
The outdoor helium compressor has an outdoor and an indoor unit. Each component has
space requirements for airflow and servicing.
The indoor component requires a space of 0.5 m (width) x 1.3 m (depth) x 1 m (height).
The outdoor component requires a space of 1.4 m (width) x 1.7 m (depth) x 1.25 m (height),
and should be sited on a concrete slab.
Sumitomo Type: F-70H (Europe) F-70L (USA) CNA-61D
Type of Compressor: Air Air
Dimension: Width: 93 cm
Depth: 33 cm
Height: 92 cm
Width: 93 cm
Depth: 33 cm
Height: 92 cm
Width: 91 cm
Depth: 40 cm
Height: 105 cm
Weight: 142 kg 142 kg 115 kg
Voltage: 3 x 460-480 V @ 60
Hz
3 x 380/400/415 V @
50 Hz
3 x 200 V @ 50/60
Hz
3 x 400 V @ 50
Hz
Mainly delivered to: EU/CH USA/CA/JP EU/CH
Operating Current: 13 A 30 A 13 A
Minimum Circuit
Ampacity:
20 A 40 A 30 A
Maximum Fuse/Circuit
Breaker Size:
30 A 60 A 30 A
Compressor LRA: 13 A 30 A 74 A
Power Consumption
Cool Down max. 50/60
Hz:
Steady State max.
50/60 Hz:
<8.0/<9.0 kW
6.9-7.2/7.9-8.2 kW
8.0/9.2 kW
7.5/8.5 kW
Acoustic Noise: Maximum < 75 dB(A) at 1m, outdoor unit only.
Ambient Operating
Temperature:
-30 to 45°C (-22 to
112°F)
-30 to 45°C (-22 to
112°F)
-30 to 45°C (-22
to 112°F)
Table10.4: Technical Data for Outdoor Compressors
