CryoProbe and Other Accessories
92 H157655_1_008
Helium Transfer line from CryoCooling Unit to CryoProbe
• A standard length transfer line, determined by the magnet, is delivered with each
CryoPlatform. Longer transfer lines may be ordered if necessary to accommodate the
CryoCooling unit in your laboratory. If a longer transfer line is required a special review of
your site will be required.
CryoPlatform
CryoCooling Unit
• Located outside 50 Gauss (5 mT) line.
• Must be serviceable from all sides.
• Must be at least 0.5 meters from walls on all sides.
Helium Compressor- Indoor Water or Air Cooled
• Located outside 5 Gauss line.
• Minimum room space is 1.25 m (width) x 0.8 m (depth) x 0.7 m (height).
• Must be serviceable from top and left side.
• The distance between the CryoCooling unit and the helium compressor component is
defined by the helium transfer lines ordered.
• Chilled water lines must be supplied to helium compressor (water cooled unit only).
• Ambient operating temperature 5º–28ºC.
Note:
The indoor helium compressor has rollers and is connected to flexible helium transfer lines.
Water-cooled models are additionally connected to water lines supplied by the customer
(typically high pressure flexible water tubing).
Helium Compressor - Outdoor Air Cooled
• Consists of one small indoor unit, one outdoor unit, and transfer lines connecting the units.
• Located outside the 5 Gauss lines (for both the indoor and outdoor unit).
• Requires indoor space of 0.5 m (width) x 1.3 m (depth) x 1 m (height).
• Requires outdoor space of 1.4 m (width) x 1.7 m (depth) x 1.25 m (height).
• The distance between the CryoCooling unit and the two helium compressor components
is defined by the transfer lines ordered.
• Ambient operating temperature for outdoor components is -30–45ºC.
Helium Cylinder
• The distance between the CryoCooling unit and the helium cylinder is defined by the
length of the He gas hose ordered.
• Must be in a serviceable location (to change cylinder and not interfere with magnet).
