First diagnosis
CryoProbe User Manual BRUKER 73 (107)
First diagnosis 7.2
0
Before you call B
RUKER, or if you have no idea how to address the problem, an-
swer the following questions (see also "CryoProbe service" on page 87
):
- which errors or warnings appear?
- what are the readings of the pressure gauges etc.?
- which parts seem to be ok/not ok?
- how did the failure occur and what happened before the failure?
- which experiment did you run or intend to do?
- is the sample special, did you do a similar NMR measurement on the
sample before either with the CryoProbe, with a conventional probe, or on
another spectrometer?
Simple checks:
- try to reproduce a standard spectrum you successfully recorded not long
ago with the same sample and identical experimental parameters.
- replace the CryoProbe with a conventional probe and run the experiment
again.
Logfile 7.2.1
On the laptop, a logfile is continuously updated with all system messages. It re-
sides in the default directory D:\app\Bruker\CryoTool\LogFiles.
Fuses and reset buttons 7.3
0
CryoCooling Unit
Automatic fuses are located on the back panel along with a melting fuse (5x20
mm, 50 mA).
To r e s e t a n E
RROR on the CryoCooling Unit front panel, press COOL DOWN if the
system is already cold or cooling down. If the CryoProbe System is warm or
warming up, press
WARM UP’.
He Compressor
See the schematics in the He Compressor operation manual for the location of the
fuses. The manual is delivered with the CryoProbe System.
HPPR CRP
There is a red reset button on the rear of the cover module
