5.
NOTICE!
Property damage due to short circuit!
– Code the humidifier only with a non-metallic
object.
Code the humidifier. To do so, use a suitable non-metallic
object to carefully position the slide controls located on the
rear side of the board (Fig. 21/1) in the same position as
those of the wireless sensor system.
6. Replace the control panel and affix it using the four screws.
7. Close the cover of the device again.
8. Check that the system functions. To do so, carefully breathe
into the housing of the wireless sensor system.
ð
The actual value indicated on the control panel changes.
The wireless sensor system is operational.
Fig. 21: Coding the humidifier
Start-up
Evaporation Humidifier B500 Professional30
