Brune B500 - Page 54

3. Lift the center piece from the water tank and place it to the
side (Fig. 44).
ð
The water pump is located at the bottom on the right-
hand side (Fig. 45/1).
4. To collect any possible residual water, place a suitable con-
tainer under the pump hoses (Fig. 46/1).
5. Remove the pump hoses.
Fig. 44: Removing the center piece
Fig. 45: Water pump
Fig. 46: Removing the pump hoses
Detecting and remedying malfunctions
Evaporation Humidifier B500 Professional54
