12 T401S Indicator User Instructions
Indicator applications
3 Indicator applications
This indicator has several weighing applications that can be enabled through a
password protected menu. Only one application can be enabled at a time. The
applications available are:
l General Weighing (explained on page 12)
l Weighing with Accumulation (explained on page 15)
l Parts Counting (explained on page 16)
l Checkweighing (explained on page 18)
l Batching (explained on page 21)
l Peak Hold (explained on page 23)
l Remote Display (explained on page 24)
The indicator comes with the default application called General Weighing active.
To display active application name
You can display the active application name by doing one of the following:
l Press and hold F1 until the numeric entry screen appears. Press F1 again to
display the current application name.
Or
l Cycle power and the current app. name is displayed briefly on power up.
3.1 General weighing application
This section applies if the General Weighing application is active. Features described
here also apply to the other applications except where noted in those application
instructions.
3.1.1 SELECT key default function
In the General Weighing application you can view the gross, net and tare display values
by repeatedly pressing SELECT.
3.1.2 Gross weighing
To perform gross weighing, power up the unit and follow these steps:
1. Empty the scale and press ZERO to zero the display …
0 is displayed and the center-of-zero annunciator ( ) lights.
2. Place item to be weighed on the scale …
Weight is displayed.
3. Repeat steps 1 and 2.
To change unit of measure, press UNITS.
