T401S Indicator User Instructions 41
8.1 General Weighing application supervisor menu
8.1.1 Setpoint
Super Setpoint
1. With the General Weighing application active, access the Supervisor menu.
Refer to Accessing the menus on page 25 for instructions. From SuPEr, press
SELECT …
SEtPnt is displayed. Use this to:
l set the function of the setpoint annunciators
l enter up to three setpoint values
l select inputs for up to three inputs
l print the setpoint settings
l reset all setpoint settings to factory defaults.
Annunciators
Setpoint Edit Annun
2. From SEtPnt, press SELECT …
Edit is displayed.
3. Press SELECT …
Annun is displayed. (Annun is not included in the Batch application
Supervisor menu. Skip steps 3 through 5).
This stands for annunciators, referring to the SP1, SP2 and SP3 setpoint
annunciators. By default (oFF) these annunciators are ON when the
displayed weight is below the setpoint value or OFF above the setpoint
value. If you select on, the annunciators work in the opposite fashion--
OFF when below, ON when above.
4. Press SELECT …
The current setting is displayed (oFF or on).
5. Press UNITS to toggle between the choices and when your choice is
displayed, press ZERO to accept …
Annun is displayed.
The and symbols used in this section stand for direction moved in the menu. So
Super Setpoint, shown above, illustrates that you move down from SuPEr to
SEtPnt. This will help you keep track of where you are in the menu structure.
A setpoint value can be entered up to scale capacity.
Turn off or disable any setpoints you are not using. See the Service manual for
information on disabling or turning off setpoints.
