T401S Indicator User Instructions 57
8.6 Peak Hold application supervisor menu
8.6 Peak Hold application supervisor menu
Figure 8.6 shows the Supervisor menu when you are in the Peak Hold application:
Figure 8.6 Supervisor menu for the Peak Hold application
8.6.1 Peak hold
Super Setpoint P-hold
1. With the Peak Hold application active, access the Supervisor menu using
password 1793. Refer to Accessing the menus on page 25 for instructions.
From SuPEr, press SELECT …
SEtPnt is displayed.
2. Press UNITS …
P-hoLd is displayed. Use this to reset the max peak value. If the F1 key
is disabled, which is the normal key to reset peak value, the supervisor
needs an alternate method to reset these values.
The Setpnt and bAttErY submenus in Figure 8.6 are the same as described in
General Weighing application supervisor menu on page 40. Go there for information
on those submenus. The unique submenus to this application are described below.
Super
Setpnt
Edit Print Reset
No
Yes
Port 1
Battery
Enable
Tmout
Off
On
P-hold
Reset
No
Yes
Port 2
Out1 Out2 Out3
Key
in
value
Key
in
value
Key
in
value
Bold boxes and text
denote defaults.
1-3600
minutes
SELECT =
TARE =
PRINT =
UNITS =
ZERO =
F1 = Escape or
To Next Page
