T401S Indicator User Instructions 51
8.4 Checkweighing application supervisor menu
8.4 Checkweighing application supervisor menu
Figure 8.4 shows the Supervisor menu when you are in the Checkweighing application:
Figure 8.4 Supervisor menu for the Checkweighing application
Follow these steps to set the items in the Supervisor menu.
8.4.1 Check
Super  Setpoint  Check
1. With the Checkweighing application active, access the Supervisor menu using
password 1793. Refer to Accessing the menus on page 25 for instructions.
From SuPEr, press SELECT …
SEtPnt is displayed.
2. Press UNITS …
chEcK is displayed. This stands for checkweigher. Use this to set the
items relating to checkweighing:
l Set under divisions for acceptable target weight (undrdiv)
Undrdiv Overdiv
Check
Super
Setpnt
Edit Print Reset
No Yes
Reset
No Yes
Battery
Enable
Tmout
Off On
Port 1 Port 2
Out1 Out2 Out3
In1
In2
In3
None
Print
Units
Select Tar e Zero
F1
Accu
PrntHld
User
Off On
Annun
Bold boxes and text
denote defaults.
1-3600
minutes
0-100 0-100
Key
in
value
Key
in
value
Key
in
value
SELECT =
TARE =
PRINT =
UNITS =
ZERO =
F1 = Escape or
The Setpnt and bAttErY submenus in Figure 8.4 are the same as described in
General Weighing application supervisor menu on page 40. Go there for information
on those submenus. The unique submenus to this application are described below.
