46 T401S Indicator User Instructions
Supervisor menu
8.2.1 Accumulator
Super Setpoint Accum
1. With the Accumulator application active, access the Supervisor menu using
password 1793. Refer to Accessing the menus on page 25 for instructions.
From SuPEr, press SELECT …
SEtPnt is displayed.
2. Press UNITS …
AccuM is displayed. Use this to set the items relating to accumulation.
Under AccuM you can do the following:
l Enable/Disable the ability to print the accumulated total (Prt tot).
l Key in a print format number for printing the total accumulated weight
information (tot FMt).
l Enable/Disable the ability to clear the total accumulation information
when the total is printed (clr tot).
l Reset the accumulator memory channel value to 0 (rESEt).
The following steps describe the procedure to set these items.
Print total
Accum Print Total
3. From AccuM, press SELECT …
Prt tot is displayed. This stands for print total.
4. Press SELECT …
oFF is displayed.
5. Press ZERO to keep the print total function disabled or press UNITS to toggle
to on and press ZERO to enable printing of the accumulated total …
Prt tot is displayed.
If enabled, during normal operation the user can press and hold PRINT
for three seconds and the selected total print format (see step 8) will be
sent out any port that is set up to printed. The display will flash Prn-tot.
Total format
Accum Print Total Total Format
6. Press UNITS …
tot FMt is displayed. This stands for the total print format.
7. Press SELECT …
The current print format number is displayed with a flashing right-most
digit. (Default is format 8)
8. Press ZERO to accept the existing setting or key in a new format number and
press ZERO …
tot FMt is displayed.
