14 T401S Indicator User Instructions
Indicator applications
3.1.4 Using setpoints
Setpoints are values (weight) at which outputs are triggered automatically. Outputs can
control relays connected to valves, lights, other machinery, etc. See the Supervisor
menu on page 39 for information on how to edit or enter setpoint values.
See the note below for an overview of how setpoints function.
3.1.5 Printing
To print the current weight information, press PRINT. The configured print format will be
output through the configured port to the connected peripheral device. The indicator
can be configured to only allow one print for each weighing sequence. If PRINT is
pressed when so configured, the message cAnt will appear.
Refer to Default print formats on page 35.
By default all setpoints are disabled. If activated, they behave differently in the
different applications. See the table below:
Below Value Above Value
General App. ON OFF
Accumulator App. ON OFF
Count App. ON OFF
Checkweigher App. SP1 - UNDER
SP2 - ACCEPT
SP3 - OVER
Batching App. ON OFF
Peak Hold App. ON OFF
Remote Display App. OFF ON
