T401S Indicator User Instructions 31
4.6 About menu
6. Press SELECT …
The version number of the bootloader is displayed.
7. Press ZERO to return to the VErSion display.
8. Press TARE to return to the boot display.
4.6.2 Firm and App
About Boot Firm and App
1. From boot, press UNITS …
FirM is displayed. This stands for firmware.
2. Repeat the same pattern of key presses in steps 2 through 7 to view the part
number and version for the FirM. and APP menu items.
4.6.3 Serial
About Boot Firm App Serial
1. With APP displayed, press UNITS …
SEriAL is displayed.
2. Press SELECT …
The first four digits of the indicator serial number are displayed. Press
UNITS to view the last five digits.
3. Press TARE to return to the SEriAL display.
4.6.4 Enet
About Boot Firm App Serial Enet
1. From oPtion, press UNITS …
EnEt is displayed. Use this item to view the values for the IP, Subnet,
Gateway and MAC addresses.
2. Press SELECT …
iP Addr is displayed. Use this item to view the four part IP address.
3. Press SELECT …
1 XXX is displayed. This is first octet of the IP address
4. Press ZERO …
2 XXX is displayed. This is second octet of the IP address.
If the indicator is connected to an ethernet network, the values displayed will be the
current assigned addresses.
