T401S Indicator User Instructions 29
4.5 User menu
7. Press UNITS …
StYLE is displayed. Use this to set the style of date for printouts.
Choices are MMDD2Y, MMDD4Y, DDMM2Y and DDMM4Y.
8. Press SELECT …
The current selection is displayed.
9. Press UNITS to scroll through the choices. Press ZERO when your choice is
displayed …
The choice is made and StYLE is displayed.
10. Press TARE …
dAtE is displayed.
4.5.3 Site ID
User Time Date Site ID
1. From dAtE, press UNITS …
SitE id is displayed.
2. Press SELECT …
A string entry screen is displayed.
See String index/character data entry on page 38 for instructions on how
to enter string characters.
3. Key in a site ID number and press ZERO to accept …
SitE id is displayed.
4.5.4 Seal
User Time Date Site ID Seal
1. From SitE id, press UNITS …
SEAL is displayed.
2. Press SELECT …
unSEALE or SEALEd is displayed. This is the status of the physical seal
inside the indicator. If the unit is sealed, no changes can be made to the
configuration of the indicator.
3. Press F1 to return to the SEAL display.
4. To exit the menu, see Exiting the menus on page 26.
The Site ID can be used in transmitted or printing information. ASCII characters 32-
126 can be used.
