T401S Indicator User Instructions 19
3.4 Checkweighing application
3.4.4 Weighing a target object
With the indicator in checkweighing mode, follow these steps to set a target by
weighing an object.
1. Press ZERO to zero the scale, if necessary.
2. Enter a tare if necessary. Refer to Net weighing on page 13 for instructions.
3. Place an object of the desired weight on the scale and press F1 …
The weight is displayed and the middle bargraph segment lights as well
as the SP2 annunciator.
4. Remove the object and replace with the next object to be checked.
The bargraph will show if the weight is under, over or within the target
weight range. If the weight is under, SP1 annunciator and the UNDER
bar segments will light. If the weight is over, SP3 annunciator and the
OVER bar segments will light.
5. Repeat step 4 until you are finished weighing items.
The current target weight will be active until you repeat steps 1 through 3 with a new
item of a different weight.
3.4.5 Setting upper and lower limits
With the indicator in checkweighing mode, follow these steps to set a target by setting
upper and lower limits.
1. Press ZERO to zero the scale, if necessary.
2. Enter a tare if necessary. Refer to Net weighing on page 13 for instructions.
3. With weight inside the gross zero band, press F1 …
Lo will be displayed briefly and then the current value for the lower
accept weight.
4. Press ZERO to accept this or key in a new lower accept weight and press
ZERO …
Hi is briefly displayed and then the current value for the upper accept
weight.
5. Press ZERO to accept this or key in a new upper accept weight and press
ZERO …
The display returns to normal weighing mode.
The acceptable target window is a range from Target Object weight ± a predefined
range entered in a password protected menu.
The farther the weight is from the target weight, more over or under bargraph
segments will light. The UNDER and OVER bargraph segments are fixed at 1 division
each.
