52 T401S Indicator User Instructions
Supervisor menu
l Set over divisions for acceptable target weight (oVErdiV)
l Reset the target values to zero.(rESEt)
Under divisions
Check Under divisions
3. Press SELECT …
undrdiv is displayed. Use this to set the number of divisions (0-100)
below the target weight that is still within the accept window.
4. Press SELECT …
The current value is shown with a flashing right-most digit.
5. Press ZERO to accept the current value or key in a new value and press
ZERO to accept …
undrdiv is displayed.
Over divisions
Check Under divisions Over divisions
6. Press UNITS …
oVErdiV is displayed. Use this to set the number of divisions (0-100)
above the target weight that is still within the accept window.
7. Press SELECT …
The current value is shown with a flashing right-most digit.
8. Press ZERO to accept the current value or key in a new value and press
ZERO to accept …
oVErdiV is displayed.
The checkweigher uses the Latch method for outputs. This means that the weight has
to stabilize before the annunciator and output for the appropriate condition (Under,
Accept or Over) are activated.
In latch mode, once activated the annunciator and output will remain unchanged until
the item is removed and the gross weight returns to inside the gross zero band.
If you are keying in the upper/lower limit as the method for setting a target weight, the
undrdiv and oVErdiV parameters do not affect the checkweighing process. They
only work for setting the acceptable range in the target weight method. See Weighing
a target object on page 19.
