42 T401S Indicator User Instructions
Supervisor menu
Outputs
Setpoint Edit Annun Out
6. Press UNITS …
out1 is displayed. This is the weight value for setpoint 1.
7. Press SELECT …
The current value is displayed with a flashing right digit.
8. Press ZERO to accept the displayed value or key in a new value and press
ZERO to accept …
out1 is displayed.
9. Press UNITS …
out2 is displayed.
Inputs
Setpoint Edit Annun Out In
10. Repeat steps 7 through 9 for out2 and out3. Press UNITS when finished …
in1 is displayed. This stands for input 1. Use this to assign a function to
input 1 when an external switch is tripped. Default choice is nonE. The
choices are listed in Figure 8.1.
11. From in1, press SELECT …
The current choice is displayed.
12. Press UNITS to scroll through the choices and when your choice is displayed,
press ZERO to accept …
in1 is displayed.
13. Press UNITS …
in2 is displayed.
14. Repeat steps 11 through 13 for in2 and in3. Press TARE when finished …
Edit is displayed.
The remote input can be used to perform an accumulated print total function. Use the
PrintHoLd function to simulate a “press and hold” of the PRINT key. If you are using
a momentary switch, press and release. If you are using a toggle switch, switch it ON
then OFF to reset the function for the next time.
Inputs and Outputs must be enabled ON in a separate password protected menu.
Some input choices will not apply in the application that is active.
