Logamatic EMS RC35 user interface - Subject to technical modifications. 13
Installation
3
3.4 User interface: attaching or removing
Attaching the user interface
1. Hook the user interface at the top into the mounting plate in the direction of the arrow.
2. Push the user interface at the bottom against the mounting plate, until it snaps into place.
Fig. 4 Attaching the user interface (left) or removing it (right)
Removing the user interface
1. Press the button underneath the mounting plate in the direction of the arrow.
2. At the same time pull the user interface forwards.
3. Remove the user interface by lifting upward.
1
2
1
2
1
AB
3
