Logamatic EMS RC35 user interface - Subject to technical modifications. 17
Operating basics
4
4.3 Overview of the Service menu
The SERVICE MENU is divided into the following menus and submenus:
Menu Submenu Contents/function Page
quick
operation
The most important parameters from the
“settings” menu for configuration of the
heating system
20
settings
(all
parameters)
system data
1)
1) Subject to restrictions depending on which boiler is used.
Parameters: language, number of heating
zones, installed modules, building type,
minimum outdoor temperature
24
boiler data
1)2)
2) Not possible or not available, depending on the boiler used.
Parameters: pump after-run time and
modulation
27
heating zone data
1)
Parameters of the installed heating zones 28
domestic hot water (DHW)
1)
Parameters for domestic hot water 37
solar data
2)
If solar is installed: see documentation
for the solar module
39
RC35 calibration Parameters: calibration of the displayed
room temperature
40
contact data Entering the heating contractor's name
and telephone number
41
diagnosis
functional test
1)2)
Activating individual components for test
purposes
42
monitor value Viewing target values and actual values 43
error message
1)
Viewing fault messages 44
heating curve Viewing the set heating characteristics
in the form of a graph
45
versions Viewing software versions 45
servicing
1)2)
service interval Setting times for maintenance, by number
of operating hours or by date
46
current messages Viewing service messages 46
RESET service Resetting service messages 46
RESET
1)
factory default set Reset all parameters 47
fault list 47
service message 47
run time 47
Tab. 5 Service menu navigator
