Entering system settings (Service menu – Settings)
Logamatic EMS RC35 user interface - Subject to technical modifications.28
6
6.3 Heating zone data
This section explains the settings for all heating zones: using heating zone 1 as an example.
B Turn the dial counter-clockwise until
heating zone 1 is selected (marked with).
B Press to select heating zone 1.
The SETTINGS\HTG. ZONE 1 menu opens.
Menu item Input range
Factory
setting
Other information
Should heating zone 1
be activated?
yes, no yes
Which user interface is
assigned to heating
zone 1?
none, RC20, RC35 RC35 (Æ page 33)
If none is selected, the control
mode is changed to outdoor reset
and will not be shown.
How should heating
zone 1 be controlled?
outdoor reset,
room reset
outdoor reset Room reset can only be set if an
RC20 or RC35 has been
assigned to the heating zone.
If there is one unmixed zone on a
system with a modulating burner,
the boiler power will used to
directly control the room
temperature; in all other cases the
supply temperature will be
controlled.
Which heating system
does heating zone 1
have?
panel radiator,
convector,
floor
panel radiator With HZ1, only use the floor
setting if the boiler is a gas
condensing boiler. Additional
heating zones can then be
installed.
A safety thermostat must be used
with radiant floor heating
regardless.
Heating curve
Design tmp
14 °F (-10 °C)
84 °F to 194 °F
(30 °C – 90 °C)
167 °F (75 °C)
(panel radiator,
convector)
113 °F (45 °C)
(floor)
Setting entered only if the control
mode has been set to outdoor
reset (Æ page 33).
Tab. 12 Navigator for Service menu SETTINGS\HTG. ZONE 1
SERVICE\SETTINGS
B
system data
boiler data
domestic hot water
heating zone 1
