Entering system settings (Service menu – Settings)
Logamatic EMS RC35 user interface - Subject to technical modifications.24
6
6 Entering system settings (Service menu –
Settings)
B Simultaneously press the + + buttons to open the
SERVICE MENU.
B Turn the dial counter-clockwise until settings is selected
(marked with).
B Press to open the SERVICE\SETTINGS menu.
6.1 System data
B Press to select system data.
The SETTINGS\SYSTEM menu opens.
Note that the menu items shown will vary depending on the heating system.
Menu item Input range
Factory
setting Other information
Which language should be
used?
American,
French,
Spanish
American
Choose units of
measurement.
US customary units °F,
metric °C/bar
Choose time format: am/pm 24h
Choose date format: MM/DD/YYYY DD/MM/YYYY
Did you install a low loss
header module?
yes, no no In connection with MCM10 the
setting is set automatically to
“yes”; the screen disappears.
Is heating zone 1 installed
(unmixed heating zone)?
yes, no yes
How many mixed heating
zones are installed?
0 to 3 0 Set the address on the dial on the
MM10 mixing module
(factory setting: HZ2).
Has a solar module been
installed?
yes, no no
Tab. 9 Navigator for Service menu SETTINGS\SYSTEM
SERVICE MENU
quick operation
B
settings
diagnosis
servicing
SERVICE\SETTINGS
B
system data
boiler data
domestic hot water
heating zone 1
