3. System Overview
This chapter provides an overview of Butterfly iQ/ iQ+/ iQ3. It includes information about its features, the
components that are included in the system, requirements necessary to download, install, and use the Butterfly
iQ App, and an overview of the user interface.
NOTES
• Depending on your platform, hardware, country and membership type, certain presets, modes
and features may not be available.
• The Butterfly iQ/ iQ+/ iQ3 and its accessories may be used multiple times on multiple patients.
Figure 1. System overview
1. Butterfly iQ/ iQ+/ iQ3 Probe.
2. Butterfly iQ application.
3. Butterfly Cloud.
4. Butterfly Cloud hospital link.
5. HL7, DICOM, PACS.
3.1. Overview
Butterfly iQ/ iQ+/ iQ3 is a hand-held general purpose diagnostic ultrasound imaging device. The system consists of
three components:
