Table 16. Butterfly iQ3 Battery Charger Specifications
Item Specification
Probe Charging Cable
(Dimensions are in mm)
Charging Standard USB Power Delivery Specification, Revision 3.0
Input Voltage DC 9V / 2 A
Input Interface USB-C
Typical Charging Power < 8.0W
Charging Efficiency >80%
Protection Over-voltage protection, Over-current protection, contact detection pin
Dimensions See photo above in “Probe Charging Cable”
Color Black
18.4. Environmental Operating Conditions
Table 17, “Environmental Operating Conditions” [94] lists the environmental conditions for the Butterfly iQ/ iQ+/
iQ3 probe only. For details on the mobile device on which you run the Butterfly iQ App, refer to the accompanying
documentation for your mobile device.
Table 17. Environmental Operating Conditions
Item
Operating Limits
Butterfly iQ/ iQ+ Butterfly iQ3
Relative Humidity Between 18-93% non-condensing Between 15% to 90% non-condensing
Altitude Between 46 m (150 ft) below sea level and 3048 m
(10,000 ft) above sea level
Between 381 m (1,250 ft) Below sea level and 4,572 m
(15,000 ft) above sea level
Operating Temperature Between 5°C to 39°C Between 0 °C to 40 °C (with relative humidity ≤15%)
Brief Storage
Temperature
The probe can withstand three days of storage at
temperatures between -20°C and 50°C
The probe can withstand three days of storage at
temperatures between -40 °C to 50 °C
Given the device is handheld, it is expected that the device will be subject to various conditions and environments,
including those present in the hospital, EMS, and home. While the device was designed to operate safely in wide
range of environments and in varying conditions, care should still be taken to protect the device from extreme
temperatures, shock, drop, and other extreme conditions. See Table 18, “Environment Compliance” [95] for a
summary of environmental compliance.
Environmental Operating Conditions
Specifications 94
