3.3. Overview of User Interface
This section provides information about the imaging display presented in the Butterfly iQ App user interface.
The app user interface will always show information about the Mechanical Index (MI) and the Thermal Index (TI) at
the top of the screen.
Depending on your Butterfly membership status and mobile app version, the toolbar at the bottom of the screen may
vary.
The toolbar at the bottom of the screen can be used for preset selection, image freeze, image capture and mode/
tool selection.
3.4. Presets
Presets are a predefined set of imaging parameter values. When selected, the Butterfly iQ App automatically
operates in accordance with the corresponding set of imaging parameter values. Presets available correspond to the
clinical applications details in Indications for Use [8]. Preset availability may also vary depending on probe, Butterfly
membership status and geographic location.
The following table shows the available presets per probe.
Table 5. Presets availability per probe
Probe
Presets
Butterfly iQ Abdomen, Abdomen Deep, Aorta & Gallbladder, Bladder, Cardiac, Cardiac Deep, FAST, Lung, MSK-Soft Tissue,
Musculoskeletal, Nerve, OB 1/GYN, OB 2/3, Ophthalmic, Pediatric Abdomen, Pediatric Cardiac, Pediatric Lung, Small
Organ, Vascular: Access, Vascular: Carotid, Vascular: Deep Vein
Butterfly iQ+ Abdomen, Abdomen Deep, Aorta & Gallbladder, Bladder, Cardiac, Cardiac Coherence, Cardiac Deep, FAST, Lung,
Lung Tissue, MSK-Soft Tissue, Musculoskeletal, Nerve, OB 1/GYN, OB 2/3, Ophthalmic, Pediatric Abdomen,
Pediatric Cardiac, Pediatric Lung, Small Organ, Vascular: Access, Vascular: Carotid, Vascular: Deep Vein, Vascular:
Superficial
Butterfly iQ3 Abdomen, Abdomen Deep, Aorta & Gallbladder, Bladder, Cardiac, Cardiac Coherence, Cardiac Deep, FAST, Lung,
Lung Tissue, MSK-Soft Tissue, Musculoskeletal, Nerve, OB 1/GYN, OB 2/3, Ophthalmic, Pediatric Abdomen,
Pediatric Cardiac, Pediatric Lung, Small Organ, Vascular: Access, Vascular: Carotid, Vascular: Deep Vein, Vascular:
Superficial
3.5. Preset Families
Certain presets which are aimed for the same or similar clinical applications are grouped together under one global
preset, this grouping is done to facilitate easier access and evaluation of the different presets for the patient being
imaged. To access the other presets within the same family tap on the screen. Additional controls will appear on the
bottom left side of the exam screen. If the preset has other presets in the same family, tapping on the presets filter
button will cycle you between the different presets within the family.
