3-4 Switches 83
3-4 Switches
Light Switch
Turn the knob at the end of the light
switch to " " to turn off all lights except
the daytime running light.
Automatic lighting
Turn the knob at the end of the light
switch to " " to allow the BCM to
automatically control the clearance
lamps and low beams to turn on or off
depending on the brightness value
collected from the light intensity sensor.
■ The illumination intensity sensor is located at the top of dashboard. Do not
cover the sensor or splatter any liquid on it.
Clearance lamp
Turn the knob at the end of the light
switch to “ ”to turn on the
clearance lamps. (Including front and
rear position lamps, rear license plate
light, backlight of dashboard, clearance
lamp indicator and some backlights).
