BYD PMW20 - Page 4

PMW20
6
PMW20
7
8.7 TABLE OF FAULT CODES
122
8.8 ELECTRICAL MAINTENANCE DIAGNOSIS
128
8.9 DESCRIPTION OF ELECTRICAL COMPONENT SYSTEM CONTROL 166
MAINTAIN TUQUE
9.1 CHECK THE TORQUE OF THE KEY FASTENERS
185
APPENDIX
10.1 TABLE OF THE TORQUE VALUE
186
10.2 ONBOARD TOOL
187
10.3 WIRING HARNESS
188
10.4 ELECTRICAL SCHEMATIC DIAGRAM
192
10.5 PARAMETERS OF THE CONTROLLER
196
OTHER INFORMATION
204
6.6 REMOVE AND INSTALL THE LIFT CYLINDER
58
6.7 COMPLETE MAINTENNACE OF THE LIFT CYLINDER
59
MAINTAIN ELECTRIC DEVICE
7.1 ELECTRIC CHECK
62
7.2 CHECK THE MAIN CONTROLLER
60
7.3 REMOVE THE MAIN CONTROLLER
61
7.4 REMOVE THE HORN
66
7.5 REMOVE THE MAIN CONTACTOR
67
7.6 REMOVE THE LIMIT SWITCH
68
TROUBLE SHOOTING
8.1 ELECTRICAL MAINTENANCE DIAGNOSIS
72
8.2 COMPARISON TABLE OF THE DISPLAY ERROR CODES AND
CONTROLLER ERROR CODES
73
8.3 PROGRAM AND SOFTWARE
76
8.4 ADJUST PARAMETERS
97
8.5 MONITOR DATA
105
8.6 BURNING PROCEDURES OF THE SERIAL PORT
112
SM-PMW202020001-EN
SM-PMW202020001-EN
OTHER INFORMATION
