PMW20
40
PMW20
41
4. Parts of the Lift Mechanism
11
13
11
23
13
11
14
12
11
13
15
16
17
21
18
19
22
12
11
20
11
10
5.13 REMOVE AND INSTALL MAIN BEARING OF COMPOUND ROLLERS
1. Remove
1) Remove cylinder fasteners and relevant wiring harness thereof (Codes 1/2/3/4/5),
and separate front and rear forklift bodies.
5.Power Wire (Input End)
of the Charger
4
.Negative and Positive Wire
(Output End) of the Charger
3.Wire Outside the Battery Box
2
.Positive Wire of the
Battery Box
1.Negative Wire of the Battery Box
SM-PMW202020001-EN
SM-PMW202020001-EN
CODE PART NAME QTY
OTHER INFORMATION
10 SERIALIZED PULL-ROD ASSEMBLY 1
11 BUSHING 10
12 ROLLER SHAFT OF THE CONNECTING ROD 2
13 ELASTIC ROUND PINS
3
14
ROLLER OF THE CONNECTING ROD
1
15
TYPE 1 HEXAGON NUT _M24
3
16
PULL-ROD CONNECTOR
1
17 ARM OF SUPPORT WHEELS-SINGLE WHEEL
1
18 ROTATING SHAFT OF ROD CONNECTOR - SINGLE WHEEL
1
19 MOUNTING SHAFT FOR SUPPORT WHEELS -Φ25×144
1
20
SUPPORT WHEEL ASSEMBLY -Φ82×110
1
21
TYPE 1 HEXAGON NUT _M8
1
22 HEXAGON SOCKET SET SCREW
1
23 LEFT CONNECTING SHAFT -325X685
1
To Next Page
